Aluminum PCB is one type of metal core printed circuit board (MCPCB), widely be used in the LED lighting industry.
If you are looking for Aluminum PCB Manufacturer, MORE PCB LTD has rich experience in manufacturing Aluminium PCB with high thermal conductivity, we offer a first-class service and extensive high-tech options.
MCPCB, Metal Core PCB, thermal PCB – whichever name you prefer, they are all boards which use a base metal material as the heat spreader portion of the circuit board. These types are typically fabricated with a metal base consisting of aluminum (most common) but can also be produced with copper.
Specification:
| Copper Thickness | 0.5-6oz |
| Board Thickness | 0.6-3.0mm |
| Min. Hole Size | 0.20mm |
| Min. Line Width | 0.10mm |
| Min. Line Spacing | 0.08mm |
| Number of Layers | 1 layer |
| Base Material | Aluminum Base |
| Surface Finishing | HAL/OSP/Immersion Gold Plating |
| Number of Layers | 1 layer |
| Service | OEM & ODM |
| Substrates material | aluminum/copper |
| Combustibility | 94v0 |
| Special technology | BGA can be 2.5mil, aperture(min)0.075mm, MID |
| Breakdown voltage | 2-4.5v |
| Thermal conductivity | 1.0-3.0w/m.k |
Application:
PCB is mainly used in automotive electronics, industrial control power supply, IT communication, medical equipment, etc., and is committed to becoming the best quality value-added service solution provider for small and medium batches and allegro production.
Deliverability:
| Layers | m² | Deliverability | m² | Deliverability |
| 2L | <1m² | 5 days | <3m² | 5 days |
| 4L | <1m² | 6 days | <3m² | 7 days |
| 6L | <1m² | 8 days | <3m² | 9 days |
| 8L | <1m² | 8 days | <3m² | 9 days |
Notes:
The standard plate is ordinary FR-4 Tg130 without a specified brand.
Minimum line width/space: 4MIL.
Inner/outer finish copper thickness: 35/35um.
Minimum aperture: 0.30MM.
Surface treatment process: lead spray, lead-free spray, OSP.
